Product Specifications

Accuracy: 0.5% (default), 0.25% (customizable)

Threads: M20*1.5, G1/4 (customizable)

Measurement Range: -0.1MPa to 0.01MPa to 60MPa

Output Signal: 4-20mA (0-5V, RS485)

2-meter lead wire supplied (original)

Warranty: Three years

Operating Temperature: -20°C to 85°C

IP65 Protection Rating: Glue-encapsulated

Case Material: 304 stainless steel

Response Time: <10ms (voltage and current signals)

Temperature Drift: <0.3%FS/10°C

Long-Term Stability: ±0.2%FS/year

Power Supply: 24VDC (9-30V wide voltage range)

Overload Pressure: 150%FS (0.035-10MPa); 125%FS (10-60MPa)
