Product Specifications

Accuracy ±0.5%R (0.5 parts per thousand)

Nominal Pressure 1.6 MPa (DN10-DN200) 1.0 MPa (DN250-DN1000) 0.6 MPa (DN1100-DN2000)

(Other specifications available on request) Flange Mounting (Default)

Mounting Method Flange Clamp Mounting (Customized) 316L Electrode (Optional)

Electrode Type  HB/HC Alloy Electrode (For Strong Acid and Alkali Environments) Titanium Electrode;

Tantalum Electrode; Tungsten Carbide Electrode; Platinum Electrode

Chloroprene Rubber (CR); Polytetrafluoroethylene (F4)

Lining Material Polyurethane Rubber (PU); Polytetrafluoroethylene (F46)

Range Ratio 10:1

Operating Environment: Operating Temperature: -10-55°C

Storage Temperature: -40-65°C

Fluid Required: Conductive Medium (Conductivity > 5µs/cm2)
